STRAW BEDDER – MOUNTED OR TRAILED – ADAPTABLE ON TELEHANDLER HELIOS PA

STANDARD EQUIPMENT
Loading
Rear hydraulic door activated by 2 cylinders

Shredding – Feeding – Mulching
1 shredding rotor mechanically driven by durable belt and automatic tightening equipped with 15 big blades predisposed to wrapped silage
Chamber with 2 retainers
Turbine Ø 1600 mm composed of 8 removable paddles
Blower housing width 320 mm in anti abrasive steel (Brinel 430 hb 120 kg steel) partly removable
Visit trap door (blower)
2 speed gearbox (feeding 270 rpm  – bedding 540 rpm) with free wheel
Fixed bedding and feeding mono-chute activated by 1 cylinder with manual dispensing slide or lateral bedding and feeding mono-chute activated by 1 cylinder
Dispense up to 18 m on the right with round bales Ø 2 m and square L 2,70 m bales

Floor conveyor
High strength Marine chain Ø 10, bars in removable rectangular tubes with manufactured ends ®
Driving of the floor conveyor by moto reductor oil bath, front and rear side with electric adjustable speed
Indicator of the floor conveyor rotation’s way

Conception – Safety
Removable bottom and sides
Dual floor with spring trap door for easy cleaning
Bolted housing on hinges
Rubber against dust

Control
Electric control of all the functions with a mobile control box in the tractor’s cab

Road traffic – Mounted model
Linkage category 3

Road traffic – trailed model
Linkage beam with bar category 2
Hydraulic mobil axle activated by 2 cylinders
Parking brake and hydraulic brake
Rear articuled light in accordance with the Highway code
Kickstand with holes
CE norms and DREAL homologation

Transmission
PTO transmission with protection, safety bowl machine side

Tractor equipment
PTO shaft for 540 rpm
Electrical plug 12v/3 pins for electric distributor
Electrical plug 12v/7 pins for light (trailed model)
Hydraulic distributor SE with direct return to the tank
Minimum of flow 25l/mn
Linkage category 3

ADDITIONAL EQUIPMENT
Chutes and equipments
– Hydraulic kit to adapt the rotation of the chute at 300°
– Bedding and dispensing chute orientation front and rear 30° – on the right hand side chute (l. 2,55m)
– Hydraulic cylinder on the chute cap

Mechanical driving
– Multi-disc clutch with oil bath for mechanical driving of the rotor

Wrapped bale dispensing
– Wrapped bale dispensing kit (+ 5 sections and 3 fixed regulators)
– Section set on the rotor (15)

Hydraulic
– Hydraulic driving of the shredding rotor
– Hydraulic regulation comb 5 teeth

Others
– Speed shifting with electric control on blower box
– Dual rear left electric control (conveyor – door)
– Rear articuled light in accordance to the Highway code (mounted model)
– Wide angle PTO transmission tractor side with protection – any used PRO will not be taken back neitheir exchanged
– Long beam with manual kickstand without linkage bar (linkage piton)
– Articuled beam for trailed model
– Atomizer (trailed model only)
– Spare wheel 10/75 x 15,3
– Linkage bar category 2
– Trailed kit after delivery

DIMENSIONS
