TPM 520

Roadside shredders | Marque : ELHO

A powerful mulcher for professional contracting!
The ELHO TPM 520 PowerArm has been designed for full-time contracting and is the perfect choice for contractors, municipalities, road maintenance teams, forest road associations and other demanding users. The extensive reach and working width provide access to even the most challenging places.
The power transmission is fully mechanical all the way to the rotor through high-powered V-belts and a bevel gear. The cutting head can be used in all positions and angles, even upside-down above the cab. Horizontal and vertical movements are adjusted hydraulically, and the PTO shaft is equipped with an over running clutch.

The TPM 520 PowerArm can be fitted to either a SideChopper 210 PRO rotor mulcher or Tornado 210 chain mulcher.
ELHO TPM 520
• Flexible: can be used in any position
• Low operating costs
• Designed in Finland for rocky conditions
• Cutting width: 2.1 metres


Are you interested in this model?

Technical specifications

  • Tractor power required, min/max, 70-110 hp
  • Recommended minimum tractor weight, 6500 kg
  • Hydraulic lateral displacement, 3 m
  • Grinding unit tilt (up/down) 180°/90°
  • Number of knives: 20
  • PTO speed, 1000 rpm
  • Hydraulic pressure, min/max 170-200 bar
  • 3-point hitch Cat.3
  • Hydraulic coupling, double action 4
  • Hydraulic unconnected return 1

Photo gallery
